STEP 15: Install the Gantry
48
1. Align the gantry right stand plate holes with the profile holes.
2. Insert (8) M5×22 screws through the right plate holes, then screw them into the profile holes and
tighten them.
Aluminum Proflie
Right Stand Plate
(8) M5×22 Round Head Screw
