GeoMax Zenith35 Pro Series User Manual

•
Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
•
This device is granted pursuant to the Japanese Radio Law (
電波法
) and the Japanese
Telecommunications Business Law (
電気通信事業法
).
•
This device should not be modified (otherwise the granted designation number will
become invalid).
Type Frequency band (MHz)
GNSS receiver GPS L1: 1575.42
GPS L2: 1227.60
GPS L5: 1176.45
GLONASS L1: 1602.5625 - 1611.5
GLONASS L2: 1246.4375 - 1254.3
Galileo E1: 1575.42
Galileo E5a: 1176.45
Galileo E5b: 1207.14
Galileo AltBOC: 1191.795
BeiDou B1: 1561.098
BeiDou B2: 1207.140
Bluetooth 2402 - 2480
Radio: 403 - 473
2G GSM Quad-Band EGSM 850/900/1800/1900
GPRS multi-slot class 10
3.75 GSM/UMTS Quad-Band GSM 850/900/1800/1900
Penta-Band UMTS 800/850/900/1900/2100
Type Output power [mW]
GNSS: Receive only
Bluetooth: 5
Radio: 500, 1000
2G GSM EGSM850/900: 2000
2G GSM GSM1800/1900: 1000
3G UMTS 800/850/900/1900/2100: 250
Type Antenna Gain [dBi]
GNSS: Internal GNSS antenna element (receive only) 28
Blue-
tooth:
Internal ceramic antenna 4.5 max.
UHF: Detachable l/4 antenna 4 max.
GSM/
UMTS:
Primary: Detachable l/2 antenna max.2dBi @
800/850/900 MHz
max. 2dBi @
1800/1900/2100 M
Hz
Secondary: Internal patch antenna max.1dBi @
800/850/900 MHz
max. 1dBi @
1800/1900/2100 M
Hz
Wi-Fi: Internal ceramic antenna 4.5 max.
Frequency band
Output power
Antenna
Technical Data 31
