The Antenna Reference Plane, ARP
The Antenna Reference Plane:
•
is where the instrument heights are measured to.
•
is where the phase centre variations refer to.
•
varies for different instruments.
The ARP for the instrument is shown in the diagram.
010014_001
a
a
The Antenna Reference
Plane is the underside of
the thread.
Description
ARP for instrument
Description of the System
15
14
