The battery is inserted at the side of the instrument.
1. To remove a battery, push the slide fastener of the battery compartment in the
direction of the arrow with the open-lock symbol and open the battery compart-
ment.
2. Push the locker sideward and at the same time pull out the battery. This releases
the battery from its fixed position.
3. Remove the battery.
4. To insert battery, push the slide fastener of the battery compartment in the direction
of the arrow with the open-lock symbol.
5. Open the battery compartment.
6. With the battery contacts facing upwards, slide the battery into the battery compart-
ment.
7. Push the battery backwards so that it locks into position.
8. Close the battery compartment and push the slide fastener in the direction of the
arrow with the close-lock symbol.
4.4 Inserting a microSD/SIM Card
•
Keep the card dry.
•
Use it only within the specified temperature range.
•
Do not bend the card.
•
Protect the card from direct impacts.
Failure to follow these instructions could result in data loss and/or permanent damage to the
card.
Inserting a microSD card
☞
Removing the microSD card while the instrument is turned on can cause loss of
data. Only remove the microSD card or unplug connecting cables when the instru-
ment is switched off.
☞
The microSD card is inserted into a slot inside the battery compartment of the
instrument.
1. Push the slide fastener of the battery compartment in the direction of the arrow with
the open-lock symbol. Open the battery compartment
☞
☞
Inserting a microSD /SIM
card step-by-step
Operation 25
