Geometrics G-882 User Manual

Geometrics Inc. G-882 Cesium Marine Magnetometer Page
80
5.0 Service Information and Trouble Shooting Guide
It is possible to open the G−882 in the field, but is not recommended. There
are no easily assessable parts that can be field serviced. It is recommended
that if service is required, the G−882 be returned to the factory for service.
5.1 Connector Information
The following Figures provide views of the connectors used on the G−882 tow
cable.
Figures 59 and 60 show the male water tight connector on the nose bulkhead
of the G−882 magnetometer. Figure 60 also shows the pin numbers for this
connector. The Geometrics part number for this connector is 21-236-400.
Figure 46
Figure 47
1
2
3
4
5
6
7
8
Figure 48
Figure 49
1
2
3
4
5
6
7
8
