75
English
SETUP
The Setup menu allows setting the available options.
To access the Setup menu, press GOTO to display the main
menu, then select SETUP by using the joystick.
The menu items are grouped in six sets.
When selecting a set by the joystick, the
list of the available options will be dis-
played. Press ENTER to select one set, then
use the joystick to switch from one option
to another and edit the setting. To go back
to the set list, press EXIT.
DISPLAY
• Mode (BRIGHT/DAY/NIGHT)
Selects the colors suitable for the environment.
• Safety Contours (OFF/2m/5m/10m/20m)
Enables the display of the areas corresponding to the depth
safety contour.
• Depth Contours (ALL/5m/10m/20m/OFF)
Selects the display of depth contours.
• Easy View (ON/OFF)
Enables/disables the Chart Magnification function.
• Markers (ON/OFF)
Enables/disables the display of markers (STD mode only).
• Chart Rotation (ON/OFF)
Enables/disables the Chart Rotation function.
• Chart Details (ON/OFF)
By selecting ON, the chart details to display (STD/USR/
ALL) can be chosen. It is possible to select one of the two
settings available (STD - equivalent to the standard display
setting, as defined by ECS regulations - and ALL, that en-
ables the display of all the items on the chart), or, by choos-
ing USER, enable/disable the display of the single items.
• Overzoom (ON/OFF)
Enables/disables the Overzoom function.
