GeoVision GV-AS2120 User Manual

GV-AS210 / 2110 / 2120 Controller
85
4
4.2.5 Connecting the Power
For GV-AS210 / 2110, you can connect the controller to power directly using the supplied
12V DC adaptor. For GV-AS2120, you can choose to supply power using a power adaptor
(available for separate purchase) or using a Power over Ethernet (PoE) adapter. After power
is connected, the power LED on GV-AS210 / 2110 / 2120 should glow.
Note: Power should be applied to the unit when all connections are completed and tested.
GV-AS210 / 2110: Use the supplied power adapter.
Power Jack
1 2 3
Power
Source
12V DC / 3A
power adaptor
Power LED
GV-AS210 /
GV-AS2110
Figure 4-8

GeoVision GV-AS2120 Specifications

General

Type	Intelligent access control reader
Certification	CE, FCC
Number of users	100000 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Access chip/card
Sustainability certificates	RoHS
Operating temperature (T-T)	0 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
DC current (max)	3 A
DC voltage range	12 - 30 V
Power consumption	200 mA
RS-485 ports	1

Weight and Dimensions

Depth	46.6 mm
Width	210 mm
Height	204 mm
Weight	810 g
