GeoVision GV-AS2120 User Manual

GV-AS210 / 2110 / 2120 Controller
87
4
4.2.6 Connecting the PC
Connecting the controller to a computer allows you to access its Web interface and connect
it to GV-ASManager if the computer is installed with GV-ASManager. The computer running
GV-ASManager software can be used to monitor the access information and alarm
messages from GV-AS210 / 2110 / 2120. If connection with GV-ASManager is interrupted,
GV-AS210 / 2110 / 2120 stores this information on the supplied micro SD card. The data
stored will be sent to GV-ASManager when connection resumes.
Figure 4-10
Note: The controllers are only compatible with the GV-ASManager versions listed below:
 GV-AS210: GV-ASManager V4.2.1 or later
 GV-AS2110: GV-ASManager V4.2.3 or later
 GV-AS2120: GV-ASManager V4.3 or later

GeoVision GV-AS2120 Specifications

General

Type	Intelligent access control reader
Certification	CE, FCC
Number of users	100000 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Access chip/card
Sustainability certificates	RoHS
Operating temperature (T-T)	0 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
DC current (max)	3 A
DC voltage range	12 - 30 V
Power consumption	200 mA
RS-485 ports	1

Weight and Dimensions

Depth	46.6 mm
Width	210 mm
Height	204 mm
Weight	810 g
