GeoVision GV-AS2120 User Manual

58
GV-AS1110
CPU 32-bit ARM7TDMI
Number of User Cards 1,000 / 40,000 cards (standalone / networked mode)
Frequency
13.56 MHz for ISO14443A (Mifare DESFire, Mifare Plus
and Mifare Classic)
Event Buffer 65,536 events and log data
Power 12V DC, 1.25A
TCP/IP Interface 1 TCP/IP interface for GV-CR420 and GV-GF1921 / 1922
Communication Protocol TCP/IP
Input 2 inputs, dry contact, NO / NC
Digital I/O
Output 1 relay output (30V DC, 1A; 110V AC~250V AC, 0.3A)
Supported ID Formats Built-in reader reads both GID and UID
Operating Temperature -35 ~ 65°C / -31 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions (W X H X D) 95 x 108 x 23 mm / 3.74 x 4.25 x 0.91 in
Weight 270 g / 0.59 lb
Ingress Protection IP66
Certification CE, FCC, RoHS
All specifications are subject to change without notice.

GeoVision GV-AS2120 Specifications

General

Type	Intelligent access control reader
Certification	CE, FCC
Number of users	100000 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Access chip/card
Sustainability certificates	RoHS
Operating temperature (T-T)	0 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
DC current (max)	3 A
DC voltage range	12 - 30 V
Power consumption	200 mA
RS-485 ports	1

Weight and Dimensions

Depth	46.6 mm
Width	210 mm
Height	204 mm
Weight	810 g
