2.3 The IR Remote Control
1 9
2
3
4
5
7
8
14
11
12
13
10
6
No.
8
Name Function
1 POWER Turn on or off the GV-IP Decoder Box / GV-Pad.
2
Numeric / Alphabetical /
Punctuation Marks /
ERASE keys
Enter numbers, alphabets or punctuation marks and erase
the entered characters.
3 BACK Back to the previous page in the Setup Menu.
4 Arrow
z Move up, down, right and left in the Setup Menu.
z Right arrow key: select a channel on the Device List.
z Left arrow key: unselect a channel on the Device List.
5
PAGE UP /
PAGE DOWN
z Go to the previous / next page on the main screen.
z Switch between the cameras on the looped view: press
the Loop Start / Stop key to stop the looped view, and
then press Page Up / Page Down to switch to the
previous / next camera.
