Gesipa FireBird Pro S - 1 Overview (See Fig. 1 - 5); 2 Blind Rivet Nut Setting Tool Firebird Pro S; Firebird Pro S GE; Use for Intended Purpose

19
GB
1. Overview (see Fig. 1 - 5)
Item Description Fig.
A Threaded mandrel 1; 3; 4
B Nosepiece 1; 3; 4
C Lock nut 1; 3; 4
D Setting piece 2
E Adjusting nut 2
F Scale 2
G Switch 1; 3
H Slide 3
x Threaded mandrel length 4
y Setting stroke 2
2. Blind rivet nut setting tool FireBird
®
Pro S /
FireBird
®
Pro S GE
2.1 Use for intended purpose
The FireBird
®
Pro S / FireBird
®
Pro S GE blind rivet nut setting tool is designed exclusively for
setting blind rivet nuts and blind rivet bolts as described in these operating instructions.
The machine may only be operated in spaces with an air temperature between 0°C and 55°C
where the relative humidity between 20 and 100 is at 100%. It is important to ensure that the
hall lighting in the operating area is sufciently bright.
Observe the safety information!
