2.4 Technical data
2.5 Equipment / accessories
3. Start-up
Prior to operating the riveting tool, you must choose the correct nosepiece and threaded man-
drel that are suitable for the nut dimensions.
3.1 Changing the threaded mandrel (Fig. 3)
• Remove the battery from the tool
• Loosen lock nut C using double open-ended spanners (WAF 24/27)
• Unscrew nosepiece B.
• Push back slide G as far as it will go.
• Unscrew threaded mandrel A
• Screw in the suitable threaded mandrel. Align the surfaces of the hexagon on the
screwed-in threaded mandrel A with the surfaces of the hexagon of slide G.
• Secure nosepiece B which is suitable for the thread dimensions with lock nut C.
Weight 2.4 kg incl. battery
Max. setting stroke 10 mm
Drive unit Brushless direct current motor
Traction power 15 kN for FB Pro
20 kN for FB Pro GE
Noise emission L
pa
76,5 dB (A), Measurement uncertainty K = 3 dB
Vibrations < 2,5 m/s², Measurement uncertainty K = 1,5 m/s²
Threaded mandrels and nosepiece
for FB Pro S M6 in working position
M4, M5 in the nosepiece holder
for FB Pro S GE M10 in working position
M8, M6 in the nosepiece holder
Tool Hexagon screwdriver WAF 4
2 double open-ended spanners, WAF 24/27 and WAF 27/30
Suspension loop Concealed in housing
Battery charger 100-240 V ~ / 50-60 Hz
Battery (quick-change) 18,0 V; 2,1 Ah
