GK-7PLUS CONTROLLER INSTRUCTION MANUAL
16
The value of this parameter can be calculated in the following way:
Factor = 100 000 / (meter turns per litre * pulses of the generator per turn)
This factor will be divided by two in the event that the type of selected generator has two 180º phase-out
channels.
Remember that the kit allows an automatic calibration that avoids making the calculation of this factor,
as it is described in the section SUPERVISOR MODE / CALIBRATION.
 FACTOR PROTECTION: If this option is activated, the stored factor in the kit will not be altered by the
parameters passed through the communication from the control software. It is an option to take into
account in the hydraulic systems where it is not possible to calculate a whole fix factor and where the
calibration must be done in an automatic way. Please consult the SUPERVISOR MODE /
CALIBRATION for more details.
 TANK: It is the number of the tank from which that hose is supplying liquid.
 SECONDS W/O PULSES: It is the time, in seconds, during which the kit will have an active supply
without a liquid pass. Once this time passes, the kit will finish the service.
 MAXIMUM QUANTITY: It is the maximum volume, in litres (or the volume unit with which is working),
that the kit will allow supplying in one go. Once this amount is achieved, the kit will finish the service.
 MAXIMUM TIME: It is the maximum time, in seconds, that the kit will have active a supply. Once this
time passes, the kit will finish the service.
3.2.5.1.4 Supervisor Mode / SUPERVISOR MENU / CONFIGURATION / GPRS (only in kits with
GPRS connection)
This option allows the parameter configuration so that the GPRS connection and the later synchronization
of information with the DieselPlus application are established.
 OPERATOR: Name of the access point (APN) given by the operator of the mobile network of the
installed SIM card.
 USER: User of the GPRS connection given by the operator of the mobile network of the installed SIM
card.
 PASSWORD: User password of the GPRS connection given by the operator of the mobile network of
the installed SIM card.
 SERVER: Domain or IP address of DieselPlus used for the communications with the GK-7PLUS
controller given by DieselPlus.
 LOCAL PORT: Listening port number of the GK-7PLUS given by DieselPlus.
 REMOTE PORT: Listening port number of the DieselPlus application given by DieselPlus.
The values of the SERVER, LOCAL AND REMOTE PORT only can be modified from the DieselPlus
application.
