2. SPECIFICATION
2.1 SPEC. TABLE
Model EXP-108W
Turntable Speed 0 –12 RPM
Turntable dia. 1650mm
Max wrapping height 2000mm
Max wrapping size 1150x1150mm
Max loading weight 1650kgs
Film stretch (%)
300% & 230% two step change by handle
(250% and 200% option)
Film tension Adjustable
Elevator Unit speed Adjustable
Max. film spec. 250x500mm∮
Turntable height 82mm
Ramp (slope) spec. 1165x1000mm
Machine size 2550x1650x2345mm
Machine net weight 516kg
Standard option:
2.5 & 3.0 meters wrapping height
Top pressure plate driven by motor
Ramp
