3.2 REMINDER OF INSTALLATION
There are some issues operators need to pay attention on:
Tower Installation
Engineers must ensure all six screws are properly installed underneath the tower,
and evenly lay out.
Control Panel Installation
Engineers must make sure the bottom-supporting arm is installed properly to the
tower with four screws and carefully fitted the tower on to the bottom-supporting arm
then installed the top-supporting arm, on top of the Control Panel. After the
installation is done, make sure, the Control Panel is 180 degree turnable.
Control Wires and Connections
On the bottom side of the Control Panel, there is one black tube, with wires inside;
carefully clipped the tube to clips on the tower and follow all the way down to the
machine base.
Motor Cover
After all the connections are complete, please carefully install the motor cover to
cover up all the wire connections and the motor on the base of the machines.
