PART LIST FOR EXP-108W
KEY NO PART NO DESCRIPTION Q'TY
1 10141020 SCREW M10x20L 4
2 PJ101200 1.65 M TURNTABLE 1
3 201BX151 BELT→1.65M 1
4 10111020 SCREW M10x20 1
5 KA0301620 BUFFER RING 1
6 KA0301910 PULLY 1
7 30302050 BEARING 6205ZZ(CWB) 1
8 KA0301610 BEARING SEAT 1
9 10100616 SCREW M6x16 2
10 KA3000130
SUPPORTING PLASTIC WHEEL ASSY→1.65M
16
11 7350TZ04 LIMIED SWITCH VL-8108 1
12 KA1103860 TURNTABLE BASE 1.65M 1
13 11301700 RING STW-17 1
14 11314000 RING R-40 1
15 30302030 BEARING 6203ZZ(CWB) 2
16 PJ101000 BELT PULLY BEARING SEAT 1
17 10100612 SCREW M6x12 3
18 KA0301940 BELT PULLY BEARING SHAFT 1
19 10111060 SCREW M10x60L 1
20 10301000 NUT M10 1
21 10111035 SCREW M10x35L 4
22 32903006 GEAR REDUCER MOTOR 1
23 KA0301930 MOTOR BELT PULLY 1
24 KA1102310 WASHER 1
25 10140816 SCREW M8x16L 1
26 PJ100800 MOTOR BOX 1
27 PJ100900 MOTOR BOX COVER 1
28 10190406 SCREW M4x6L 4
29 KA110254A COVERING PLATE 1
30 10170610 SCREW M6x10 4
31 PJ100500 FIXED PLATE 2
32 KA0200040 WIRING BOX 1
33 91000020 LOADCELL SENSOR 4
