PART LIST FOR EXP-108W
KEY NO PART NO DESCRIPTION Q'TY
1 PJ200300 TOWER COVER (TOP) 1
2 10251025 SCREW M10*25L 4
3 74602002 ELEVATOR UNIT SPEED REDUCER 1
4 PJ201200 GEAR 1
5 PJ201400 SPEED REDUCER BEARING SEAT 1
6 3030202N BEARING 6202-2NR 1
7 10170508 SCREW M5x8L 4
8 PJ200500 SENSING PLATE 2
9
PJ20010A
PJ20011A
PJ20012A
TOWER→ 2 M
TOWER→ 2.5 M
TOWER →3 M
1
1
1
10 PJ309900 SNAKE WIRING COVER SEAT 1
11 7067C063 SNAKE WIRING COVER 1
12
PJ200200
PJ200210
PJ200220
COVER PLATE→ 2 M
COVER PLATE→ 2.5 M
COVER PLATE→ 3 M
1
1
1
13 10111235 SCREW M12x35L 2
14 10331200 NUT M12 2
15 10251025 SCREW M10x25L 6
16 10181080 SCREW M10x80L 2
17 PJ201500 GEAR SHAFT 1
18 PJ201300 GEAR 1
19 30300020 BEARING 6002ZZ (CWB) 1
20 11301500 RING STW-15 2
21 10250820 SCREW M8x20L 1
22
3240S401
3240S402
3240S407
CHAIN→ 2 M
CHAIN→ 2.5 M
CHAIN→ 3M
1
1
1
23
24
25 PJ201700 CHAIN ADJUST SEAT 1
