PART LIST FOR EXP-108W
KEY NO PART NO DESCRIPTION Q' TY
1 PJ400400 SUPPORTING TUBES 2
2 PJ400500 SUPPORTING SEATS 2
3 10100840 SCREW M8x40 8
4 PJ400100 ELECTRICAL BOX 1
5 PD400520 HINGE 2
6 PJ400300 WIRING PLATE 1
7 PD400610 PLATE 2
8 PJ400210 ELECTRICAL BOX DOOR 1
9 PA201810-01 LOCK 2
10 10190425 FLAT PHILIP SCREW M4x25L 1
11 PB400400 CIRCUIT BEAKER KEY 1
12 PA202100 SPRING 2
13 10330400 LOCK NUT 2
14 10130435 ROUND PHILIP SCREW M4x35L 4
15 7365P002 CIRCUIT BEAKER KEY 1
16 10130412 ROUND PHILIP SCREW M4x12L 2
17 PD400400 SECURITY SWITCH SEAT 1
18 KA1103880 DISPLAY SEAT 1
19 KA0200030 DISPLAY 1
