Getac P470 - Left-Side Components

Getting Started 1-7
Left-Side Components
Ref
Component
Description
See Also

Microphone
Connector
Connects an external microphone.
P. 2-21

Audio Output
Connector
Connects a set of headphones, external
speakers with amplifier, or an audio recording
device.
P. 2-21

RF (radio
frequency)
On/Off Switch
Turns the wireless LAN radio, Bluetooth
radio, and WWAN on/off.
P. 2-25,
2-28

USB Port
Connects a USB device, such as a USB flash
disk, printer, digital camera, joystick, and
more.
P. 4-5

Mini IEEE 1394
Port
Connects an IEEE 1394 device such as a
scanner, printer, DVCAM, VCR, and more.
P. 4-6

ExpressCard/54
Slot
Accepts an ExpressCard/34 or
ExpressCard/54 for additional functions.
P. 4-11

Stylus
Provides a convenient way to use the
touchscreen. Can be stretched for better grip
and handling.
P. 2-12
