Getac X600 User Manual

10
Ref Component Description
The near infrared (IR) imaging
capability allows you
to use Windows Hello face authentication.

Camera lens
(optional)
Allows you to use the camera function.

Camera cover
(optional)
Covers the camera lens.
Slide the camera cover toward the right to use the
camera; slide it toward the left for privacy protection.

LCD screen Displays the output of the computer.
Select models have the touchscreen feature.

Keyboard Serves as the data input device of the computer.

Touchpad Serves as the pointing device of the computer.

Indicators
Power Lights green when computer is on.
Blinks green when computer is in Sleep mode.
Battery Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this
period.
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks red rapidly (once per 0.5 second) when there
is a thermal protection problem. Ask for repair
service in case this happens.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this
happens.
Caps Lock
Lights green when Caps Lock is on.
Num Lock
Lights green when Num Lock is on.

Getac X600 Specifications

General

Charging port type	DC-in jack
USB 2.0 ports quantity	0
Combo headphone/mic port	Yes
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	-
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Storage temperature (T-T)	-51 - 71 °C
Operating temperature (T-T)	-29 - 63 °C
Operating relative humidity (H-H)	0 - 95 %
Cable lock slot type	Kensington
Trusted Platform Module (TPM) version	2.0
On-board graphics card family	Intel® UHD Graphics
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Total storage capacity	1000 GB
AC adapter power	150 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Battery voltage	10.8 V
Battery capacity	6900 mAh
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	128 GB
Processor cache	12 MB
Processor cores	6
Processor model	i5-11500H
Processor family	Intel® Core™ i5
Processor frequency	- GHz
Processor cache type	Smart Cache
Processor boost frequency	4.6 GHz
Operating system architecture	64-bit
Panel type	LCD
Display diagonal	15.6 \
Display brightness	1000 cd/m²
Native aspect ratio	16:9
Pointing device	Touchpad
Form factor	Clamshell
Product type	Laptop
Product color	Black

Weight and Dimensions

Depth	322 mm
Width	412 mm
Height	52.5 mm
Weight	- g
