• Adjust the adjustable feet, so the module is level with the floor of the room. If the washer-
disinfector is to be installed in a pit, it is a good idea to measure the depth of the pit before
adjusting the feet. If the pit's depth is 150 mm, the adjustable feet must be lengthened approx.
50 mm, as illustrated below. This means that the extended length of the feet must be 100 mm
less than the depth of the pit.
Three people are required for this step. Two to lift the module and one to hold the
rear of the module.
• Lower the lower end of the module into the pit, stand it on the front pair of wheels and push it
towards the middle of the pit. Lift the module into a vertical position and check that the
module's legs are on the pieces of plating.
