INSTALLATION REQUIREMENTS
General Description
Washer-disinfectors in Getinge's 9100-Series are large capacity, floor loading jet spray washers for
mechanical washing, intermediate level (A0 value = 600 as standard) thermal disinfection and drying of
moisture and temperature stable hospital carts, sterilization containers, material handling carts, stands
and utensils.
The washer can be installed in a shallow pit or installed at level floor level. When installed in a pit, the floor
of the washer’s chamber is level with the room floor, which allows the direct loading and unloading of
carts. When the washer is installed at floor level, the floor of the chamber is higher than the room floor.
Ramps are then provided as standard equipment to facilitate loading and unloading.
The washer has a number of side spray nozzles arranged on spray arms (on either side of the chamber).
Available as an accessory is a docking mechanism in the floor, for docking wash carts with spray arms.
Detergent and rinse aid solutions are dispensed automatically as a standard feature.
The washer is fitted with one or two doors. Two doors create an airlock function between the soiled and
clean sides of the machine. The doors are horizontal sliding doors. The washer-disinfector is available in
four different sizes: the models 9120, 9125, 9128 and 9122.
Wash chamber interior dimensions
Model
Door Width Door High Load Length
9120 960 (38”) 2000 (80”) 2000 (80”)
9125 960 (38”) 2000 (80”) 2500 (98”)
9128 960 (38”) 2000 (80”) 2850 (112”)
9122 1170 (46”) 2200 (86”) 2200 (86”)
Model Identification
The rating plate for washer-disinfectors in the 9100-Series is affixed to the electrical cabinet. Make a note
of the model type and serial number (S/N) from the rating plate.
TYP:_______________________________________________________________________
SERIENUMMER:____________________________________________________________
Always include the model type and serial number when communicating with Getinge Disinfection AB.
Utilities and Specifications
Utility requirements and specifications are included on the appropriate rough-in drawings (pit mounted or
floor mounted version).
Installation Advisory
Washer-disinfectors are assembled at the factory, tested and then disassembled for shipment. Extensive
on-site reassembly is required. The installation instructions in the Installation Manual are intended as the
primary reference for accomplishing this reassembly. Every effort has been to make this information as
accurate as possible.
Washer-disinfector options
The 9100-Series washer-disinfectors may be equipped with the following options.
Page 7 of 92
