• Remove the packing frame.
• Clean the surface where the sealing strip is to be placed.
• Place the sealing strips on the two ends of the main module.
• Apply silicone in the lower corners of both ends of the module. Apply the silicone from the
corner and about 20 cm up along the edge where the strip will be placed. Also apply silicone
from the corner and about 20 cm in towards the middle of the main module, along the edge
where the strip will be located.
Note: It is very important that the sealing strip follows the edge of the seal plate.
Be sure not to take any short cuts in the corners.
000633
1
1
1
1
1
1
1. Sealing strip
Page 18 of 92
<Doc_INS><Doc_6001341302><Rel.A><Lang_en>
