Size
There are four different models of washer-disinfectors in the 9100 series; see the section Wash chamber
interior dimensions, Page 7. The washer comes in modules; see the section Unpacking, Page 12 .
Dimension and weight of the largest modules
9120 9125 9128 9122
Main module
unit
Dimensions
(mm)
(inches)
1350 × 2440 ×
1203
53 × 96 × 47
1350 × 2440 ×
1203
53 × 96 × 47
1350 × 2440 ×
1203
53 × 96 × 47
1560 × 2640 ×
1203
61 × 104 × 47
Weight (kg)
(lb)
250
551
250
551
250
551
280
617
Chamber
extension
module
Dimensions
(mm)
(inches)
1315 × 2445 × 415
52 × 96 × 16
1315 × 2445 ×
665
52 × 96 × 26
1315 × 2445 ×
840
52 × 96 × 33
1315 × 2445 ×
515
52 × 96 × 20
Weight (kg)
(lb)
105
232
150
331
177
390
138
304
Glass Door Dimensions
(mm)
(inches)
1095 × 2100 × 35
43 × 83 × 1.5
1095 × 2100 ×
35
43 × 83 × 1.5
1095 × 2100 ×
35
43 × 83 × 1.5
1095 × 2100 ×
35
43 × 83 × 1.5
Weight (kg)
(lb)
100
220
100
220
100
220
130
287
Floor Mount or Pit Mount
For a floor-mounted washer-disinfector, ramps are required to access the washer-disinfector. The inner
floor of a pit-mounted washer-disinfector is at the same level as the area's floor.
Right Side or Left Side Service Area
Provide access to components such as plumbing, valves, pumps, tanks, electrical cabinet, etc. The
location of service area on your washer can be located left or right hand.
One or two doors
One door for loading/unloading on the same side, or two doors - one for loading on soiled side and one
for unloading on clean side.
Horizontal or inclined sliding door
As standard, the door opens horizontally, straight to the side. An inclined sliding door is required if the
unit is mounted in a pit with a width of 1900-2400 mm. The sliding doors open toward the service area.
Steam or electric heating
The heating elements for water, drying and the booster tank are heated with the building's steam or
electricity.
Connection for treated water
Connection for treated water in addition to hot and cold water, which are standard.
