GEZE Perlan AUT-NT
6
Operation
Operation6
The set parameters of the drive functions may only be modied by properly trained persons.
Commissioning and the setting or modication of the door parameters as well as of some special drive functions
can be carried out by using the DIP switches on the controller (see wiring diagram Perlan AUT-NT,
Mat. No. 139997).
Operating modes6.1
Dead-man
The drive continues to move in the direction as long as its button is pressed or the signal is applied. In case of
obstacles the sliding door drive stops.
Semi-automatic
The drive moves in the direction of the pressed button or of the applied signal. The drive does not close automat-
ically after an opening pulse. It remains in the open position and only closes after a renewed closing command.
The sliding door drive stops in case of obstacles, a stop signal or control commands against the current direction
of movement.
Automatic
In addition to the semi-automatic operating mode the sliding door drive closes automatically after the set hold-
open time.
In the case of obstacles in the closing direction the door opens again and closes automatically after the set hold-
open time. In the case of control commands against the current direction of movement the sliding door drive
reverses. At a stop signal the sliding door drive stops for the duration of the stop signal. When the stop signal
drops again, the door moves further in the direction of movement previously selected.
Single permanent opening
In order to induce a unique permanent opening in automatic mode the OPEN and CLOSE buttons have to be kept
pressed for longer than 2 seconds. The sliding door drive does not close automatically after this opening pulse. It
remains in the open position and only closes after a closing command (press CLOSE button). After the close com-
mand the sliding door drive is back in automatic mode.
Display of the operating mode6.2
The operating mode is indicated by the green LED at the operating panel. During an automatic cycle it lights up
continuously as long as the sliding door drive is moving. During the hold-open time the LED ashes, in semi-
automatic mode the LED ashes during the movement.
The red LED ashes rapidly in case of a fault (system fault).
Clearing a system fault:
Press the Reset button for at least 2 seconds.
