Error display
Error display7
If the safety functions recognize a fault, the controller changes to the fault state.
In this case the driver block and the safety relay are deactivated rst.
The following system states have been dened for the fault recognition:
Fault
code
Name Description Fault elimination
0 System OK No fault –
1 Unknown fault Unknown cause of fault Switch mains voltage o/on.
X
Carry a reset as described in
X
Chapter 6.2.
Replace the controller if neces-
X
sary.
2 Self-test – several faults The self-test has recognised several faults
4 Self-test – oscillator fault The self-test has recognised a defective
oscillator
Replace the controller.
X
5 Self-test – relay defective The self-test has recognised a defective
relay
6 Self-test – driver defective The self-test has recognised a defective
driver
7 Self-test – current measure-
ment defective
The current measurement does not func-
tion properly
Switch mains voltage o/on.
X
Carry a reset as described in
X
Chapter 6.2.
Replace the motor and/or con-
X
troller if necessary.
8 Self-test – driver fault recog-
nition defective
The power driver no longer outputs a fault
message
–
9 Hardware – encoder fault The encoder is not connected correctly or
is defective
Check the encoder connection.
X
Replace the motor or controller.
X
10 Hardware – voltage impos-
sible
The supply voltage lies outside the per-
missible range
Replace the power pack.
X
Replace the controller if neces-
X
sary.
11 Memory – RAM defective A defect has been recognised in the RAM Replace the controller.
X
12 Memory – ROM defective The programme memory has been
changed or is defective
13 Memory – EEPROM defec-
tive
The data memory is defective
A fault state is indicated by ashing codes of the two LEDs on the controller:
First the red LED ashes rapidly, then it lights up continuously for approx. 20 seconds. During these 20 seconds
the green LED ashes in accordance with the fault code x times. The cycle repeats until the user resets the fault.
Example: Green LED ashes 4 times, i.e. Fault code 4. This corresponds to a defective oscillator.
Red LED:
Green LED:
