Staircase control unit THZ
46
Commissioning
No. 5 4 3 2 1 Parameter Value
14
*
● ● ● ○
Set battery monitoring 00 Battery monitoring inactive, no display at battery fault
(operation without battery)
01 Battery monitoring active, only display
02 Battery monitoring active, OPEN all windows at fault
03 Battery monitoring active, CLOSE all windows at
fault
15
*
● ● ● ●
Behaviour at internal fault 00 Only display of the fault
01 Open all windows at power failure
02 Close all windows at power failure
16
* *
○ ○ ○ ●
Smoke detector remote resetting
via RWA CLOSE/RESET
00 / 01 o / on
17
* *
○ ○ ● ○
Alarm reinitiation (VdS 2581) 00 / 01 o / on
18
* *
○ ○ ● ●
Function Signal relay 1 00 Alarm
01 Fault (general)
*)
02 Window OPEN
03 Time-limited alarm (300 s)
04 Time-delayed alarm (10 s)
05 Battery fault
06 Detector line fault
07 Motor line fault
08 Power failure
*)
09 "Reset Alarm" as pulse (1 s)
19
* *
○ ● ○ ○
Function Signal relay 2 00 Alarm
01 Fault
*)
02 Window OPEN
03 Time-limited alarm (300 s)
04 Time-delayed alarm (10 s)
05 Battery fault
06 Detector line fault
07 Motor line fault
08 Power failure
*)
09 “Reset Alarm” as pulse (1 s)
20
* *
○ ● ○ ●
Function Signal relay 3 00 Alarm
01 Fault
*)
02 Window OPEN
03 Time-limited alarm (300 s)
04 Time-delayed alarm (10 s)
05 Battery fault
06 Detector line fault
07 Motor line fault
08 Power failure
*)
09 “Reset Alarm” as pulse (1 s)
21
* *
○ ● ● ○
BMZ input 00 BMZ latching function
01 Without BMZ latching function (dead-man function)
22
* *
○ ● ● ●
Motor runtime 00 s … 300 s … 720 s max. motor runtime in s
***)
23
**)
* *
● ○ ○ ○
Internal vent switch 00 / 01 o / on
24
**)
* *
● ○ ○ ●
Brightness illumination of inter-
nal RWA switch
00 Deactivated
0 … 10 Brightness changes directly
10 = 100%
25
* *
● ○ ● ○
Motor operating mode 00 Motor connection for standard motor
01 Motor connection for retention magnet
