GEZE THZ - Operating States and Error Messages

Staircase control unit THZ
47
Commissioning
No. 5 4 3 2 1 Parameter Value
42
* * *
● ● ○ ○
Firmware update 00 System in normal operation
01 System in programming mode
43
* * *
● ● ○ ●
Test charge voltage 00 Test charge voltage o
01 Load voltage 10 s on
Display ×
○
* *
○
44
* * *
● ● ● ○
Reset to factory setting 00 Parameters are not reset
01 Parameters are reset
45
* * *
● ● ● ●
DIsplay of the software version e.g. 01-04-00 for V1.4
*) connections NC and NO swaped
**) Only available for version THZ comfort
***) Motor running time closing after CLOSED/Reset or
rain/wind is always 720s, repeated CLOSE/Reset starts
time again
6.1.5 LED value table
5 4 3 2 1 Value 5 4 3 2 1 Value 5 4 3 2 1 Value
○ ○ ○ ○ ○
00
○ ● ○ ● ●
12
● ○ ● ● ○
55
○ ○ ○ ○ ●
01
○ ● ● ○ ○
14
● ○ ● ● ●
60
○ ○ ○ ● ○
02
○ ● ● ○ ●
16
● ● ○ ○ ○
120
○ ○ ○ ● ●
03
○ ● ● ● ○
18
● ● ○ ○ ●
180
○ ○ ● ○ ○
04
○ ● ● ● ●
20
● ● ○ ● ○
240
○ ○ ● ○ ●
05
● ○ ○ ○ ○
25
● ● ○ ● ●
300
○ ○ ● ● ○
06
● ○ ○ ○ ●
30
● ● ● ○ ○
360
○ ○ ● ● ●
07
● ○ ○ ● ○
35
● ● ● ○ ●
480
○ ● ○ ○ ○
08
● ○ ○ ● ●
40
● ● ● ● ○
600
○ ● ○ ○ ●
09
● ○ ● ○ ○
45
● ● ● ● ●
720
○ ● ○ ● ○
10
● ○ ● ○ ●
50
6.2 Operating states and error messages
6.2.1 Operating states
5 4 3 2 1 Operating state
○ ○ ○ ○ ●
System ready, no re alarm
○ ○ ○ ● ○
Rain/Wind input active, system ready
○ ○ ○ ● ●
Fire alarm RWA switch
○ ○ ● ○ ○
Fire alarm smoke detector
○ ○ ● ○ ●
External re alarm (BMZ)
○ ○ ○
* *
Alarm cancelled, alarm signal RWA switch active
○ ○
*
○ ○
Alarm cancelled, alarm signal smoke detector active
○ ○
*
○
*
Alarm cancelled, alarm signal ext. re alarm (BMZ) active
○
*
○ ○ ○
Service interval expired
(LED 4 ashes, in addition to further displays)
Fault at power failure
X
Press the S1 button.
The fault message is displayed.
