Ghost Controls DTP1 - Page 35

35
PULLTOOPEN
©Ghost Controls 2018
E. Now you can mark and drill the inner most hole on the front mount bracket, shown below.
Mark and drill
center location of
innermost hole
CL
F. Align the innermost hole of the estate and front mount brackets and insert (1) M8 x 65mm flat washer,
and (1) M8 nylon locknut through both holes and tighten to secure the bracket to the gate. YOUR FRONT
MOUNT AND ESTATE BRACKET SHOULD NOW BE ATTACHED AND SECURED TO THE GATE.
G. Align and attach arm of operator to the secured front mount bracket, as shown below. Make sure all parts
installed during installation are tightened down.
