A17: Saddle support
A18: Dérailleur
A19: Seat stay
A20: Head tube
A21: Rim
A22: Down tube
A23: Front wheel
A24: Rear derailleur wheel
A25: Kickstand
A26: Hub, front, front wheel hub
A27: Seat clamp screw(s)
A28: Type plate (on the seat tube)
A29: Display (mounted on the handlebars)
A30: Front mudguard
A31: Rear mudguard
A32: Headlight (front light)
A33: Back light (rear)
A34: Luggage rack
A35: Chain guard / chain case
A36: Cassette / sprocket set
Illustration B
B1: Brake lever
B2: Grip (handlebar grip)
B3: Headset
B4: Handlebars
