Illustration C
C1: Gear cable
C2: Dropout
C3: Derailleur hanger
Illustration D
D1: Fork steering tube
D2: Fork tube
D3: Dip tube
Illustration E
E1: Seatpost clamp bolt E3: Quick-release axle
E2: Seatpost clamp, clamp E4: Quick-release lever
