Giada MI-D2700D - Autopw_On; Power ATX20 Pin

22
21
www.giadatech.com
4.11 AUTOPW_ON.
4.12 Power ATX20 Pin.
4.13 F_ PANEL (Front-end control panel).
AUTOPW _ON
3*1 PIN 2.54mm
I
1
2
3
AUTO_PW R_ON
BUTTON_PSW
1
11
10
20
Definition
3.3V
-12V
GND
PS-ON
GND
GND
GND
-5V
5V
5V
PIN
11
12
13
14
15
16
17
18
19
20
Definition
3.3V
3.3V
GND
5V
GND
5V
GND
PG
5VSB
12V
PIN
1
2
3
4
5
6
7
8
9
10
This socket is used to connect the flat cables on the front-end panel.
1
2
9
10
