In case the SSM is too close to or interfering with the RIDESENSE, install them
at location away from each other (ensure end of the device 2~3mm away from
the edge of SSM). Otherwise, the SSM may hit the RIDESENSE and result in
damage. See figure below for correct installation position.
(Ensure end of the device 2~3mm away from the
edge of SSM.)
Remove RIDESENSE: G
Remove the screw, push the device forward, compress and deform the silica gel
before pulling it upward, remove it carefully without damaging the antenna
compartment. Insert the seat stay plug in the fix opening for RIDESENSE after it
was removed.
