1. With Gibson G FORCE off, tune your guitar to a custom tuning.
2. Press On three times. Press Enter.
3. Press the Left button once to select the string LED, then press and hold Enter for more
than 3 seconds to engage Pitch Assist.
4. When a string flashes red, pluck it. (Tip: Mute a string after its string LED turns green to speed
up the process.)
5. When a string LED flashes blue, use the Left/Right buttons to select a blue bank preset. Press
Enter = stores pitch-corrected tuning in the selected preset.
Reference Tuning
Tune the guitar to itself, but reference a non-standard pitch
Example: A piano is in tune with itself, but slightly flat. Tune one string to the piano, make that the
reference pitch, and the guitar will be in tune with the piano.
Note: Loading any other tuning erases the reference tuning. To save this tuning as a user tuning preset,
treat it as a Custom Tuning and follow the steps in Custom Tuning above. Do not use Pitch Assist.
1. With Gibson G FORCE off, tune one string to the new reference pitch.
2. Press On three times. Press Enter.
3. Press the Left button twice to select the string LED. Press Enter.
4. E string flashes red. Use the Left/Right buttons to select the string you tuned to the new
reference pitch.
5. Pluck the string. When the string LED shines green and all others red, strum to tune the guitar.
6. LEDs turn off = reference tuning is complete.
Firmware Version
Display Gibson G FORCE firmware version number
1. With Gibson G FORCE off, press On three times. Press Enter.
2. Press the Left button three times to select the string LED. Press Enter.
3. You’ll see three sequences of lit LEDs. The number of lit green LEDs is the version number’s first
digit, the number of lit blue LEDs is the second digit, and the number of lit red LEDs is the third
digit. All LEDs = zero. Example: 2 lit green LEDS + 3 lit blue LEDs + 1 lit red LED = version
2.3.1
4. The sequence occurs rapidly. If you need to see it again, press Enter.
