Contents
1 General information .......................................................................................................................... 3
2 Standard Specifications .................................................................................................................... 3
3 Maintenance and Customer Service................................................................................................. 3
4 Operating Instructions....................................................................................................................... 3
5 Instruction of Operative Personnel.................................................................................................... 3
6 Key for code designation ................................................................................................................. 3
8 Boiler connection measures.............................................................................................................. 4
9 Installation of flange ......................................................................................................................... 4
10 Inserting the Nozzle .......................................................................................................................... 5
11 Adjustment of the ignition electrodes ................................................................................................ 5
12 Adjusting the Jet Linkage (Dimension "A“) ....................................................................................... 5
13 Air adjustment ................................................................................................................................... 6
14 Electrical connection ......................................................................................................................... 8
15 Oil connection ................................................................................................................................... 9
16 Oil pump............................................................................................................................................ 11
17 Start-up ............................................................................................................................................. 12
18 Control Unit LMO .............................................................................................................................. 13
19 Troubleshooting ................................................................................................................................ 15
20 Adjustment table .............................................................................................................................. 16
21 Explosion drawing ............................................................................................................................ 17
22 Parts list ........................................................................................................................................... 19
23
Declaration of Conformity ................................................................................................................. 20
24 Burner construction measures ......................................................................................................... 22
25 Working ranges................................................................................................................................. 22
1 General information
The installation of an oil-fired system must conform to extensive regulations and requirements. It is there-
fore the duty of the installer to be familiar with all applicable regulations and requirements. Installation, start-
up and maintenance must be performed with utmost care. Fuel oil type EL to DIN 51603 must be used.
The burner must not be operated in rooms with high levels of air humidity (laundry rooms), dust or corrosive
vapours.
Manually operated shut-off valve
Before the burner or typically means a manually operated shut-off valve for separating the burner must be
installed. It must be easily accessible.
Filter and venting device
Upstream of the burner, a filter must be installed to prevent the ingress of foreign matter. To vent the fuel
feed line proper facilities shall be provided.
