GIGA-BYTE TECHNOLOGY B365M DS3H User Manual

1-7 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) LED_C
6) SATA3 0/1/2/3/4/5
7) M2A
8) F_PANEL
9) F_AUDIO
10) SPDIF_O
11) F_USB30
12) F_USB1/F_USB2
13) COM
14) LPT
15) TPM
16) BAT
17) CLR_CMOS
4 1 3
2
11
12
7
10
85 4139 1514
6
6
17
16
- 12 -

GIGA-BYTE TECHNOLOGY B365M DS3H Specifications

General

Brand	GIGA-BYTE TECHNOLOGY
Model	B365M DS3H
Category	Motherboard
Language	English
