- 32 -8S651MP-RZ Series Motherboard
English
SYSTEM FAN Fail Warning
Disabled Fan Warning Function Disable. (Default value)
Enabled Fan Warning Function Enable.
Frequency/Voltage Control
CPU Clock Ratio [10X]
Linear Frequency Control [Disabled]
x CPU Clock (MHz) 100
x DRAM Clock (MHz) AUTO
x AGP Clock (MHz) AUTO
x PCI Clock (MHz) AUTO
CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware
Frequ ency/Vol tage Con trol
higf: M ove Enter: Select +/-/ PU/PD: V alue F10: Save ESC: Exit F1: General Help
F5: P revious V alues F6: Fail-Save De fault F7: Optimiz ed Defa ults
Item Help
Menu Level u
CPU Clock Ratio
This setup option will automatically assign by CPU detection.
For Willamette CPU:
8X~23X default: 14X
For C-Stepping P4:
8X,10X~24X default: 15X
For Northwood CPU:
12X~24X default: 16X
The option will display "Locked" and read only if the CPU ratio is not changeable.
Linear Frequency Control
Disabled Disable this function. (Default value)
Enabled Enable this function.
CPU Clock
100~355 Select CPU Clock to 100MHz~355MHz.
If you use FSB400 Pentium 4 processor, please set "CPU Clock" to 100MHz.If you use FSB533
Pentium 4 processor, please set "CPU Clock" to 133MHz. If you use FSB800 Pentium 4
processor, please set "CPU Clock" to 200MHz.
Incorrect using it may cause your system broken. For power End-User use only!
DRAM Clock (MHz)
Please set DRAM Clock according to your requirement.
If you use DDR200 DRAM module, please set "DRAM Clock(MHz)" to 200. If you use DDR333
DRAM module, please set "DRAM Clock(MHz)" to 333.
Incorrect using it may cause your system broken. For power End-User use only!
