- 28 -8S651MP-RZ Series Motherboard
English
Parallel Port Mode
SPP Using Parallel port as Standard Parallel Port.
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port. (Default Value)
ECP+EPP Using Parallel port as ECP & EPP mode.
EPP Mode Select
EPP 1.9 Compliant with EPP 1.9 version.
EPP 1.7 Compliant with EPP 1.7 version.(Default Value)
ECP Mode Use DMA
3 Set ECP Mode Use DMA to 3. (Default Value)
1 Set ECP Mode Use DMA to 1.
Game Port Address
201 Set Game Port Address to 201. (Default Value)
8209 Set Game Port Address to 209.
8Disabled Disable this function.
Midi Port Address
290 Set Midi Port Address to 290.
300 Set Midi Port Address to 300.
330 Set Midi Port Address to 330.(Default Value)
Disabled Disable this function.
Midi Port IRQ
5 Set Midi Port IRQ to 5.
10 Set Midi Port IRQ to 10. (Default Value)
Power Management Setup
ACPI Suspend Type [S1(POS)]
Soft-Off by PWR_BTTN [Off]
System After AC Back [Off]
IRQ [3-7, 9-15], NMI [Enabled]
ModemRingOn [Enabled]
PME Event Wake Up [Enabled]
Power On by Keyboard [Disabled]
Power On by Mouse [Disabled]
Resume by Alarm [Disabled]
x Month Alarm NA
x Day (of Month) 0
x Time (hh:mm:ss) 0 0 0
Power LED in S1 state [Blinking]
CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware
Powe r Manag ement S etup
higf: M ove Enter: Select +/-/ PU/PD: V alue F10: Save ESC: Exit F1: General Help
F5: P revious V alues F6: Fail-Save De fault F7: Optimiz ed Defa ults
Item Help
Menu Level u
[S1]
Set suspend type to
Power On Suspend under
ACPI OS
[S3]
Set suspend type to
Suspend to RAM under
ACPI OS
To Next Page
