- 59 -
Conguring SATA Hard Drive(s)
The selection bar will move to the Disks section on the right of the screen. Select the hard drives to be included
in the RAID array. Use the up or down arrow key to select a hard drive and press <Insert>. The selected hard
drive will be shown in green. To use all of the hard drives, simply press <A> to select all. Then press <Enter>
and the selection bar will move to the User Inputsectionontheleftbottomofthescreen.(Figure10)
Figure 10
Figure 11
First, select a RAID mode and press <Enter>. The selections available depend on the number of the hard drives
beinginstalled.Thenfollowtheon-screeninstructionstospecifythearraysize.YoucanselectAll available
spacetousethemaximumsizeallowedorusetheupordownarrowkeytoadjustthesize(Figure11)and
press <Enter>.
AMD-RAID Array Conguration (Build: 6.1.1-00075)
RAID0: Stripe set - distributes space across disks for higher performance
Arrays
Create Array
<
h
><
i
><
f
><
g
>=Choose, <Esc>=Back
<Enter>=Select Menu Item
0-00, 79GB, Ready
1-01, 79GB, Ready
User Input
Disks
Disks: 0, 1
Type: RAID 0
Select Array Type to Create
RAID5 RAID10N
RAID0 RAID1N
RAID1 Volume
RAID10 RAIDABLE
RAID50
Available Keys
AMD-RAID Array Conguration (Build: 6.1.1-00075)
Arrays
Create Array
<PAGEUP><
h
><PAGEDOWN><
i
>=Change Size
<Enter>=Complete, <Esc>=Go Back
0-00, 79GB, Ready
1-01, 79GB, Ready
User Input
Disks
Disks: 0, 1
Type: RAID 0
Total Size: 158GB
Choose Size to Make Array
Size Chosen: All available space
DOS Size: 147GB
Exactly: 158, 892, 818, 432
Available Keys
