- 11 -
Hardware Installation
Storage Interface (M2_10G, SATA Express, and SATA3 4/5 connectors can only be used one at a
time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is
installed in the M2_10G connector.)
Chipset:
- 4 x SATA 6Gb/s connectors (sSATA3 0~3), supporting IDE and AHCI modes
only
(An operating system installed on the SATA3 0~5 connectors cannot be used on
the sSATA3 0~3 connectors.)
USB Chipset:
- 4 x USB 3.0/2.0 ports (available through the internal USB headers)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Chipset + 2 Renesas
®
uPD720210 USB 3.0 Hubs:
- 8 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x PCIe power connector
1 x SATA Express connector
10 x SATA 6Gb/s connectors
1 x M.2 Socket 3 connector
1 x CPU fan header
1 x water cooling fan header (CPU_OPT)
3 x system fan headers
1 x heatsink LED power connector
1 x I/O shield audio LED power connector
1 x front panel header
1 x front panel audio header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1 x Thunderbolt add-in card connector
1 x Clear CMOS jumper
1 x power button
1 x reset button
1 x Clear CMOS button
1 x Direct to BIOS button
2 x BIOS switches
Voltage Measurement Points
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x CPU overclocking button
1 x Fast Boot button
1 x Clear CMOS button
8 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
2 x RJ-45 ports
2 x SMA antenna connectors (2T2R)
