- 26 -
1-10 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) ATX4P
4) CPU_FAN
5) SYS_FAN1/2/3
6) CPU_OPT
7) LED_CON1
8) LED_CON2
9) SATA_EXPRESS
10) SATA3 0/1/2/3/4/5
11) sSATA3 0/1/2/3
12) CLR_CMOS
13) M2_10G
14) F_PANEL
15) F_AUDIO
16) SPDIF_O
17) F_USB30_1/F_USB30_2
18) F_USB1/F_USB2
19) THB_C
20) BAT
2
14
9
18 13515
3
1
6
11
5
4
20
1719 12
10
5
8
7
16
10
17
