Gigabyte GA-X99-UD7 WIFI User Manual

- 8 -
GA-X99-UD7 WIFI Motherboard Block Diagram
Fordetailedproductinformation/limitation(s),referto"1-2ProductSpecications."
LGA2011-3
CPU
CPUCLK+/-(100MHz)
Dual BIOS
PCI Express Bus
PCIe CLK
(100MHz)
DMI 2.0
4 SATA 6Gb/s
LPC Bus
Center/Subwoofer Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Rear Speaker Out
PS/2 KB/Mouse
iTE
®
Super I/O
Intel
®
X99
Side Speaker Out
CODEC
4 USB 3.0/2.0
6 USB 2.0/1.1
4 Channel Memory
SATA Express
M.2
or
Switch
2 SATA 6Gb/s
or
4 SATA 6Gb/s
4 USB 3.0/2.0
Renesas
®
uPD720210 Hub
4 USB 3.0/2.0
Renesas
®
uPD720210 Hub
PCI Express Bus
PCIe CLK
(100MHz)
Switch
x16
x16
1 PCI Express x16
2 PCI Express x8
or
x16 x8
1 PCI
Express x8
1 PCI
PCI Express x16
3 PCI Express x1
x1
x1
x1
RJ45
Intel
®
GbE
LAN phy
x1
RJ45
Intel
®
GbE
LAN
x1
LAN2LAN1
x1
M.2 Wi-Fi
Wi-Fi Module
DDR42133/1866/1600/1333MHz
