Gigabyte GA-X99-UD7 WIFI User Manual

- 22 -
Hardware Installation
Theaudiojackscanbereconguredtoperformdifferentfunctionsviatheaudiosoftware(supported
functionsmayvarybasedonhardwarespecication). If you install a Side Speaker, you need to retask
other audio jack to be Side Speaker out. Only microphones still MUST be connected to the default Mic
in jack. Refertotheinstructionsonsettingupa2/4/5.1/7.1-channelaudiocongurationinChapter6,
"Conguring2/4/5.1/7.1-ChannelAudio."
Optical S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital optical audio.
Before using this feature, ensure that your audio system provides an optical digital audio in connector.
Line In Jack (Blue)
The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.
Line Out Jack (Green)
The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended
thatyouconnectyourheadphone/speakertothisjack(actualeffectsmayvarybythedevicebeingused).
Use this audio jack for a headphone or 2-channel speaker. This jack can be used to connect front speakers
ina4/5.1/7.1-channelaudioconguration.
Mic In Jack (Pink)
The Mic in jack. Microphones must be connected to this jack.
SMA Antenna Connectors (2T2R)
Use this connector to connect an antenna.
Tighten the antenna cables to the antenna connectors and then move the antenna to a place where
the signal is good.
