Gigabyte MD72-HB0 User Manual

Hardware Installation - 28 -
1-8 Jumper Settings
Jumper Name Jumper Setting
Clear CMOS
1-2 Closed: Normal operation (Default setting)
2-3 Closed: Clear CMOS data
J1 ON OFF
1 HOST_SMBUS_SEL BIOS dened
2 PMBUS_SEL BIOS dened
3 S3_MASK
Stop inial power on
when BMC is not ready
Normal [Default]
4 DB_PLD CPLD debug mode Normal [Default]
J2 ON OFF
1 ME_UPDATE Force ME update Normal [Default]
2 BIOS_PWD Clear supervisor password Normal [Default]
3 BIOS_RCVR BIOS recovery mode Normal [Default]
4 ME_RCVR ME recovery mode Normal [Default]
Clear CMOS
CLR_CMOS
EnableDefault
123
-
21',3

-
21',3


