BIOS Setup
- 82 -
2-4-3
BMC VLAN Conguration
Parameter
Description
BMCVLANConguration
BMC VLAN ID
SelecttocongureBMCVLANID.Thevalidrangeisfrom0to4094.When
set to 0, BMC VLAN ID will be disabled.
BMC VLAN Priority
SelecttocongureBMCVLANPriority
.Thevalidrangeisfrom0to7.
When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.
