1-2 Product Specications
Form Factor
E-ATX
305W x 330D (mm)
CPU
3rd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor,
Intel® Xeon® Silver Processor
10nm technology, CPU TDP up to 270W
2 x LGA 4189; Socket P+
Chipset
Intel® C621A Express Chipset
Memory 16 x DIMM slots
DDR4 memory supported only
8-channel memory architecture per processor
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHz
LAN 2 x 10Gb/s BASE-T LAN ports (Intel® X710-AT2)
(Note)
2 x 1Gb/s LAN Ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
Onboard
Graphics
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage Interface
2 x 7-pin SATA 6Gb/s ports
3 x SlimSAS with 12 x SATA 6Gb/s ports
RAID
Intel® SATA RAID 0/1/10/5
Expansion Slots Slot_6: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0
Slot_5: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0
Slot_2: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0
Slot_1: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
2 x M.2 slot:
- M-key
- PCIe Gen4 x4 per slot
- Supports NGFF-22110/2280 cards
- From CPU
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.
(Note) MD72-HB0 Only.
