Gigabyte MD72-HB0 User Manual

- 6 -
Item Code Description
1 SW_ID ID Button with LED
2 USB3_MLAN1 Server Management LAN Port (Top)/USB 3.0 Ports (Bottom)
3 10GLAN1 10GbE LAN Port #1 (MD72-HB0 Supported)
4 10GLAN2 10GbE LAN Port #2 (MD72-HB0 Supported)
5 LAN1_2 GbE LAN Port #1 (Top)/GbE LAN Port #2 (Bottom)
6 COM1 PJ45 Type Serial Port
7 VGA VGA port
8 P12V_AUX3 2x3 Pin 12V Power Connector (for PCIe)
9 CPU1_FAN CPU1 Fan Connector
10 P12V_AUX2 2x4 Pin 12V Power Connector (for CPU1)
11 SYS_FAN1 System Fan Connector #1
12 PMBUS1 PMBus Connector
13 ATX3 2x12 Pin Main Power Connector
14 SYS_FAN5 System Fan Connector #5
15 P12V_AUX1 2x4 Pin 12V Power Connector (for CPU0)
16 SSATA_SGP SATA SGPIO Connector
17
CPU0_FAN CPU0 Fan Connector
18 SATA1 Slimline SAS 4i Connector (SATA 6Gb/s Signal)
19 SATA0 Slimline SAS 4i Connector (SATA 6Gb/s Signal)
20 SSATA0 Slimline SAS 4i Connector (SATA 6Gb/s Signal)
21 10GACT2/10GACT1 10G LAN2 Active LED/10G LAN1 Active LED
(MD72-HB0 Supported)
22 FP_1 Front Panel Header
23 F_USB1 Front Panel USB 3.1 Connector
24 SYS_FAN2 System Fan Connector #2
25 SYS_FAN3 System Fan Connector #3
26 SYS_FAN4 System Fan Connector #4
27 M2M_1 M.2 Slot #1 (PCIe Gen4 x4, Support NGFF-22110/2280)
28 M2M_0 M.2 Slot #0 (PCIe Gen4 x4, Support NGFF-22110/2280)
29 SW_RAID SATA RAID Upgrade Key
30 SSATA4 SATA III 6Gb/s Connector #4
31 SSATA5 SATA III 6Gb/s Connector #5
32 LED_BMC BMC Firmware Readiness LED
33 SPI_TPM TPM Connector
34 BAT Battery Socket
35 BP_1 HDD Back Plane Board Connector
36 CASE_OPEN Case Open Intrusion Alert Header
37 IPMB IPMB Connector
38 SLOT1 PCIe x16 Slot (Gen4 x16) From CPU1
39 SLOT2 PCIe x16 Slot (Gen4 x16) From CPU0
40 SLOT3 PCIe x16 Slot (Gen4 x16) From CPU0
41 SLOT4 PCIe x16 Slot (Gen4 x16) From CPU1
42 SLOT5 PCIe x16 Slot (Gen4 x16) From CPU1
43 SLOT6 PCIe x16 Slot (Gen4 x16) From CPU0
