GILGEN F4 - Control Elements; Safety Elements; Technical Data

0546-999-33---36c_2010.04.indd
F4
0546-999/34c
Page 8 of 16
Operator manual
3.6 Control elements
The possible control elements are:
3.7 Safety elements
3.8 Technical data
• Mains power supply 230 VAC, 50 Hz, 10/13 A
• Motor 230 VAC, 50 Hz, 0,26 kW
• Dimensions Height 165 mm, Width 756 mm, Depth 149 mm
• Weight approx. 22 kg (incl. rod assembly)
• Opening time of the output
shaft for 180° 3,5...8 s
• Hold-open time 0...30 s
• Maximum rotation angle
of the output shaft 210°
• Door opening angle 70...95°
• Ambient temperature -15...+50 °C
• The unit may only be
used in dry rooms max. relative humidity 70 %
• Protection type IP 30
Element
Safety element "reversing"
Safety element "Stop"
Electric lock/Electric door opener*
Potential-free contact "Door moving"
(max. 48 V/1 A)
Stop piece in OPEN position
Example
maximum 2 light barriers
maximum 1 infrared light scanner
maximum 2 infrared light scanners
locked or unlocked without mains power
signalling lamp
Element
Opening element (inside/outside)
Opening element (outside NIGHT)
Opening element
External program switch
Example
Radar, Sensor, Push-button, Remote
radio control with AUTOMATIC or stepping
switch control
Key-operated impulse switch
Door latch contact (wiper contact)
OFF-AUTOMATIC-OPEN-EXIT-NIGHT
