SAFETY
The swing door drive unit FDC-E has been designed for the automatic operation of
swing doors. For any use outside of the dened application purposes or limits, the
manufacturer respectively his distribution agent decline all responsibility.
In order to guarantee a safe and reliable operation of the swing door drive unit FDC‑E,
it is absolutely indispensable that the conditions prescribed by the manufacturer with
regard to installation, operation, maintenance and repair be strictly fullled. If these
regulations are not observed, the manufacturer respectively his distribution agent
cannot be held responsible.
Should it not be possible to eliminate immediately any malfunctions
which are liable to cause a dangerous situation, the operator of the
installation has to be informed and, if required, the installation must
be taken out of operation.
PRODUCT DESCRIPTION
Normal operation
The swing door drive unit FDC-E allows an automatic opening and closing of swing
doors. The functional characteristics of the door can be determined by means of the
program switch as well as the internal switches and potentiometers.
Program switch position:
1 = AUTOMATIC Automatic operating mode. All the control elements are active.
The installation is not locked.
0 = MANUAL Corresponds to an operation without mains power. The door can
or be manually opened and closed.
NIGHT In cases where an external electric door opener is provided,
the door will be locked during the night.
2 = OPEN The installation opens and remains in the OPEN position.
Control
The door is opened either automatically or manually via the control elements. It is
closed as soon as the programmed hold-open time has expired. If the Push and Go-
function is enabled, a manual push against the door causes the drive unit to carry out
an automatic opening motion.
