Click "Gain" to adjust the wave's gain, viz. Amplification factor.
Click "Single lead" to change the lead no. and display the ECG of appointed lead.
Click "SV" to display all the strip graph of the appointed kinds in the current ECG.
Prompt:
The strip graph is a graph that it can plot a single lead ECG wave in a quadrate area and mark the
beginning time and average heart rate. The wave of 3.5s after the beginning time is the main
wave.
Pressing "Ctrl" key on the keyboard and clicking the left key of mouse on one strip graph can
select it to change the attribute or delete. The background of the selected strip graph will turn
black. The same operation can also cancel the selection.
The following is the introduction taking example for "Max HR".
Click "Max HR" in the menu as Fig.6-12, and the strip graph of the max heart rate will appear,
which is for the main analytical lead. Of course, the physician can choose other leads according
to the needs by
button (as Fig.6-13).
